Electrolux Smart Variomix Service Manual

58
Fästelement Utgåva Månad År
Attachment element Edition Month Year
Befestigungsteile Ausgabe Monat Jahr
4 06 2008
Art.nr Anm.
Art. no Benämning Description Bezeichnung Notes
Art. Nr Anm.
Fet stil = Ändring
Bold print = Change
Fettdruck = Änderung
552 20 25-00 Korgmutter Cage nut Korbmutter M5
552 21 21-02 Flänsmutter Flange nut Flanschmutter M5
53 92 88-32 Bricka Washer Scheibe BRB 6,4x38 RFR
53 92 88-51 Bricka Washer Scheibe BRB 8,5x38 RFR
722 78 43-02 Popnit Blind rivet Popniete 4x10,3
732 31 14-40 Kupolmutter Dome nut Kappenmutter MHM 5 RFR
732 31 16-40 Mutter Nut Mutter MHM 6 RFR
736 28 28-51 Slangklämma Hose clamp Schlauchklemme Ø 38
736 28 43-90 Slangklämma Hose clip Schlauchschelle Ø 75
736 28 55-90 Slangklämma Hose clip Schlauchschelle Ø 138
478 56 64-03 Skruv Screw Schraube LKCS 5x10 RFR
725 53 29-40 Skruv Screw Schraube MC6S 5x16 RFR
725 54 51-40 Skruv Screw Schraube MC6S 8x20 RFR
728 83 21-09 Skruv Screw Schraube SK6SS 5x6 RFR
728 84 47-09 Skruv Screw Schraube SK6SS 8x12 RFR
734 11 24-09 Bricka Washer Scheibe BRB 3,2x7 RFR
734 11 36-09 Bricka Washer Scheibe BRB 4,3x9 RFR
734 48 84-40 Bricka Washer Scheibe BRB 5,2x15 RFR
734 11 46-09 Bricka Washer Scheibe BRB 5,3x10 RFR
734 49 17-40 Bricka Washer Scheibe BRB 6,5x16 RFR
734 11 64-09 Bricka Washer Scheibe BRB 8,4x25 RFR
734 11 73-09 Bricka Washer Scheibe BRB 10,5x21 RFR
734 11 78-09 Bricka Washer Scheibe BRB 13x24 RFR
724 12 28-40 Skruv Screw Schraube MRX 3x16 RFR
724 12 89-40 Skruv Screw Schraube MRX 4x10 RFR
724 12 92-40 Skruv Screw Schraube MRX 4x14 RFR
724 13 23-40 Skruv Screw Schraube MRX 5x8 RFR
724 13 31-40 Skruv Screw Schraube MRX 5x20 RFR
725 23 27-40 Skruv Screw Schraube M6S 5x12 RFR
725 23 31-40 Skruv Screw Schraube M6S 5x20 RFR
725 23 66-40 Skruv Screw Schraube M6S 6x12 RFR
725 23 70-40 Skruv Screw Schraube M6S 6x20 RFR
725 23 78-40 Skruv Screw Schraube M6S 6x40 RFR
725 24 49-40 Skruv Screw Schraube M6S 8x16 RFR
725 24 53-40 Skruv Screw Schraube M6S 8x25 RFR
725 24 69-40 Skruv Screw Schraube M6S 8x90 RFR
725 24 95-40 Skruv Screw Schraube M6S 10x30 RFR
725 25 11-40 Skruv Screw Schraube M6S 10x100 RFR
731 23 10-40 Mutter Nut Mutter M6M 3 RFR
731 23 12-40 Mutter Nut Mutter M6M 4 RFR
731 23 16-40 Mutter Nut Mutter M6M 6 RFR
731 23 18-40 Mutter Nut Mutter M6M 8 RFR
731 23 20-40 Mutter Nut Mutter M6M 10 RFR
735 11 36-40 Fjäderbricka Elastic washer Federscheibe FBB 4,1 RFR
735 11 46-40 Fjäderbricka Elastic washer Federscheibe FBB 5,1 RFR
735 11 53-40 Fjäderbricka Elastic washer Federscheibe FBB 6,1 RFR
735 11 64-40 Fjäderbricka Elastic washer Federscheibe FBB 8,2 RFR
735 11 73-40 Fjäderbricka Elastic washer Federscheibe FBB 10.2 RFR
