Electrolux TT300 - Central Control Panel (CP) Operation; CP Control Panel Layout

Instructions for use
14
487 18 39 01 - 300/500/750 - GB
A. Filter: When the lamp is lit, the filter must be cleaned.
B. Not active on machines controlled by a central control panel.
C. Operating lamp/indicator: Ready to start.
D. Timer button, not active on payment machines.
E. Start/stop button.
F. Temperature selection button.
G. Lamps: lit to indicate selected temperature.
H. Temperature.
1
2
3
4 5
G
H
A
D E F
B
C
Machine controlled by a central control panel (CP)
