Installation - gas heating
487 18 39 01 - 300/500/750 - GB
43
2
4
3
1. Nozzle
2. Measuring branch
3. Nipple
4. Adjusting screw
Type 300/30, 500/50, 750/75/650
300/30
500/50
750/75
650
Gas valve
1
1
Gas installation
