Electrolux W475 - Repairs

100
5
5204
Heating
Repairs
Repair work on the machine should only be
done by specially trained personnel.
Replacingtheheatingelements
Wen replacing the heating elements, there
is a risk that water still left in the machine
may flood onto the floor. Be sure to dry up
any spilled water since it may cause people
to slip and hurt themselves.
 1. Takedownpowerfromthemachine.
 2. Removethefrontcover.
 3. Makeanoteofhowtheheatingelementsare
connected.
 4. Disconnecttheconnectiontotheheating
element to be replaced.
 5. Unscrewthenutbetweentheconnections
approx.1cm.
 6. Pushonthenutandbolttoundotheexpan-
sionbracketfromtheouterdrum.
 7. Removetheoldheatingelementandinstall
thenewone.Besurethattherearedgeis
ttedintotheelementholderattherearofthe
outer drum.
 8. Assembleinreverseorder.
5
Heatingelement
Temperature sensor
