Electrolux W475 - Function Options for Type 1 and Type 2 I;O Modules

58
Function options for Type 1 and Type 2 I/O modules
Function options, I/O module Type 1
A B C D E
Waste Waste Waste Waste Waste
Heating Heating Heating Heating Heating
3Hotwater 3Hotwater – 1Hotwater 1Hotwater
3Coldwater 4Coldwater 4Coldwater 5Coldwater 1Coldwater
Function options, I/O module Type 2
A B C D E F G
Externalslot
meter
Startblock Startblock Pricereduc-
tion
PC5 Startblock Heatswitch
Pricepro-
gramming
Start/Pause Heating
pause
Heating
pause
Heating
pause
Heating
pause
Start/Pause
Detergent
tankempty
Detergent
tankempty
Detergent
tankempty
Detergent
tankempty
Detergent
tankempty
Detergent
tankempty
Detergent
tankempty
Temporary
pause
Temporary
pause
Temporary
pause
Temporary
pause
Temporary
pause
Temporary
pause
Temporary
pause
5 detergent
signals
5 detergent
signals
5 detergent
signals
5 detergent
signals
5 detergent
signals
5 detergent
signals
5 detergent
signals
1program-
me signal
1program-
me signal
Free mach-
ine
1program-
me signal
1program-
me signal
1program-
me signal
Gasheating
I/O modules
