Detergent compartment
Description
Thedetergentcompartmentofthemachineis
designedforusewithpowderandliquiddeter-
gent.Thecompartmentisdividedintofoursub-
compartmentsasfollows:
• Compartment1-Forprewashwithpowder
or liquid detergent.
• Compartment2-Formainwashwithdeter-
gent powder.
• Compartment3-Rinse.
• Compartment4-Mainwashwithliquidde-
tergent or, bleaching-agent.
Theconnectionsforincomingwateraresituated
ontherearsideofthecompartment.Compart-
ments3and4eachhaveoneconnector,while
compartments1and2eachhavetwocon-
nectors,oneforcoldwater,theotherforwarm
water.
Thedetergentisroutedfromthebottomofthe
compartment to the outer drum through the
combo module immediately behind the compart-
ment.
Tosafeguardagainstoverlling,e.g.,duetoa
blockedhoseonitswaytothedrum,thecombo
modulefeaturesanoverowdraindirectlycon-
nectedtothedrainofthemachine.
1
2
Detergentcompartment
 1 Compartment2:Mainwash,
powder detergent
 2. Compartment4:Mainwash,
liquid detergent or bleaching-
agent
3. Water connections
 4. Overowdrain
5. Water connections
 6. Towashingdrum
 7. Compartment3;Rinse
 8. Compartment1:Pre-washwith
powder or liquid detergent
Detergent compartment
