Heating
Heating
Description
Electricheating
Theheatingsystemofthemachineconsistsof:
• Threeheatingelementsforheatingthewater
in the drum.
• Atemperaturesensortodetectthewater
temperature in the drum.
• Oneortwoheatingcontactorsforswitch-on/
switch-offoftheheatingelements.
The heating elements and the temperature sen-
soraresituatedatthebottomoftheouterdrum
closetotheedge.Theycanbeaccessedfront
thefrontafterthefrontplateisremoved.
Thecontactor(s)is(are)placedintherearcontrol
unit.
Dependingonthesizeofthemachine,thefol-
lowingheatingelementsareshownasexample.
Further is available.
Machine Heatingelementsize
model (kW)
W465H 3x0.665,3x1,3x1.8,3x2.5
W475H 3x0.665,3x1,3x1.8,3x2.5
W475N/S 3x0.665,3x1,3x1.8,3x2.5
W485N/S 3x0.665,3x1,3x1.8,3x2.5
W4105H/N/S 3x2.53x3.3
W4130H,W4180N/S 3x2x2.165
W4130N/S 3x2.5x3.3
W4180H,W4250N/S 3x2x3.0
W4240H 3x2x3.83
W4300H,W4330N/S 3x2x3,83
1
Heatingelementsand
temperature sensor
Contactor
