Door and door lock
Function
Thedoorlocklocksthedoor
Whenthedoorisclosed(closeddoorlockswitchS3),theprogrammeunit
mayrequestdoorlockingbyapplyingavoltageof200-240Vonthedoor
lockcontrollerA31inputX92.
ThefollowingcheckismadebytheA31cardpriortolockingofthedoor:
• No water in drum-input"level"fromlevelguardB2isclosed=0V
• Drum not turning-pulsefrequencyoninput"Tacho"fromrotation
sensorB3lessthan0.4Hz.
Whentheaboveconditionsaremet,thecardA1outputsaclosingpulse
onoutputD0tothedoorlockactuator/coil,whichthenlocksthedoor.The
microswitchesS4aandS4bintheactuator/doorlockareclosedwhenthe
doorislocked.Thesemicroswitchesfeedvoltageto:
• The output relays on the programme unit card. The relays control the
machine’sdrainandwatervalvesaswellasheaterswitch-on.
• Interlock signalformotorcontrol(inputX302)thatreleasesthemotor
start prevention state.
Programmeoperationisnowpossible.
2
 1. ProgramunitA1
 2. TemperaturesensorB1
 3, LevelswitchB2
 4, LevelswitchB4
 5. DisplayA2
 6. HeaterelementE1-3
 7. MotorcontrolU1
 8. RotationsensorB3
 9. DoorlockmoduleA41
 10. VoltageunitA5,PSU
 11. I/Oboard
 12. Watervalves
 13. Drainvalve
 14. Powersupply
