Electrolux W475 - Description

80
1
6565,6660
Motor and motor control
Description
Motor
The motor is fitted in a bridge carrier under the
outer drum. It drives the washing drum using a
drive belt.
Themotorisfrequency-regulatedandiscon-
trolled by a microcomputer control. The vari-
ousspeedsfornormaloperation,distribution
speedsandextractionaswellasacceleration/
retardation can be controlled with a high de-
greeofprecision.
The motor winding is protected against over-
loadduetothefactthatthemotorcontrolunit
monitorsthewindingresistanceofthemotor.
The motor is connected directly to the motor
controllerviaacablewithquickconnectors.
ThiscablecontainstwofusesandaVDR-resis-
tance.Thesizeofthefusesaredifferentdepen-
dingonmachinesize.
W465H,W475H,W4105H  10A
W4130H    15A
W4180H,W4240H,W4300H  20A
W475S,W485S,W4105S,W4130S 10A
W4180S    15A
W4250S,W4330S   20A
ForW475NandW485Nthefusesareinthe
PSUunitandthecablehasonlyaVDR-
resistance.
W4105N,W4130N   10A
W4180N    15A
W4250N,W4330N   20A
Motor
RotationsensorB3
1
