Electrolux W475 - Repairs

93
5222
4
Drain valve
Repairs
Repair work on the machine should only be
done by specially trained personnel.
Disassembly
For repair works on the drain valve, there is
a risk that water still left in the machine may
flood onto the floor. Be sure to dry up any
spilled water since it may cause people to
slip and hurt themselves.
 1. Takedownpowerfromthemachine.
 2. Removethefrontcover.
 3. Disconnectthedrainhosefromupperpartof
the valve.
 4. Undothehoseclampholdingthevalverub-
berbellowsagainstthesleevecouplingofthe
outer drum.
 5. Loosenandunscrewthe4retainingnutsof
thevalveacoupleofturns(useasocket,
extenderandratchetwrench).Turnthevalve
andunhookitfromthebolts.
 6. Disconnectthepressurehosefromthelower
partofthevalve.
 7. Replacethevalvewithanewoneorreplace
thedefectivepart.
3
4
4
7
6
5
2
1
3
3
9
101772
8
 1. Upperpart
 2. Rubberdiaphragmwithdrainconnection
 3. Pressureplate
 4. Recoilspring
 5. Cylinder
 6. Piston
 7. Diaphragm
 8. Nippleforconnectionoffeedhosefrom
control valve
 9. Lowerpart
