Motor and motor control
Repairs
Repair work on the machine should only be
done by specially trained personnel.
Motorreplacement
Disassembly
 1. Takedownpowerfromthemachine.
 2. Removetherearcover.
 3. Undothebracketforthedrainhoseconnec-
torfromthelowerrearpiece,thenremovethe
rear cover.
 4. Undothegroundconnectionfromthemotor.
 5. Removethedrivebeltbypullingthebelt
towards you while rotating the drum by hand.
 6. Undothemotorcablefrommotor.
 7. Lockthemotorinplacetoavoiditfromfalling
whenliftingitout.
 8. Undoandremovethetwomotormounting
bolts.
 9. Liftoutthemotor.
 10. Replacethesensorandmagnetfromtheold
motor into the new one.
Assembly
 1. Fitthenewmotor withoutlockingthemoun-
ting bolts.
 2. Fitthedrivebeltandadjustthebelttension
withthetensionerononesideofthemotor.
SesectionAdjustments-Drivebelttension
fordetails.
 3. Connectthenewmotortothecableanduse
straps to secure the cable.
 4. Connectthemotorcabletothemotor.
5. Fit the lower rear piece and secure the drain
hose connection with screws.
 6. Fittheupperrearpiece.
 7. Connectthevoltagesupplyandverifythatthe
motor operates normally.
8
Motorcable
Mountingbolt
Spacer
H – model
S och N – model
Motorcable
