I/O modules
Replacement of I/O module
I/Omodules1and2areinstalledinthesame
way,butarelocatedindifferentpartsofthe
machine.Thefollowingillustrationonlyshows
howtoreplaceI/Omodule2,butthesamepro-
cedurealsoappliestoI/Omodule1.
I/Omodule2islocatedontherearPCBandac-
cessible once the protective plate is removed.
• Removetheelectricalconnectionsonthe
module.
• Usingascrewdriver,undothelockscrew
holding the module in position.
• Rotatethemoduletotheleft.
• Liftoutthemodule
• Fitthenewmodulebyreversingtheremoval
procedure.
Terminalblock
8
9
10
11
