• Connection8maybeconnectedifthereistobeapauseinthewash
program, e.g. while detergent is being dosed.
 Thegureshowsanexampleofengaginga24Vpausesignal.Thewash
programwillpauseforaslongasthepausesignalremainsactive(high).
• Ifconnection7isconnected,anerrormessagewillbeshowninthe
displayifanyofthechemicaltanksareempty.However,thewashpro-
gram will continue.
 Thegureshowsanexampleofengaginganormalopencontact.
