Connectionofexternaldosingsystems
6Connectionofexternaldosingsystems
6.1Connectionofthehoses
Themachineispreparedforconnectionofexternaldosingsystemsorwaterre-usesystemsetc.
Theconnectionsareclosedatdelivery.Openanyoftheconnectionsthatshallbeusedbydrilling
aholewherethehosesshallbeconnected.
Note!
Makesurethereisnoburrsleftafterdrilling.Whenremovingburrsmakesureburrsdoes
notfallintothesiphonbreaker.
A=⌀17mm(usedforexternaldosingsystemsorsystemsforre-useofwater).
B=⌀6mm(usedforexternaldosingsystemsonly).
C=Onlyusedforexternalliquidmanifold.(Separateinstructionsenclosedwhenordering).
⑭
A
B
C
AlwaysconnecthosesonconnectionsAwithahoseclamp.
ForconnectionsB;ifthehosesaremadeofasoftmaterialsuchassilikonorsimilair,usea
cabletietofastenthehoseontheconnection.Ifthehosesaremadeofahardmaterial,itisnot
recommendedtomaketheconnectiontighterbyusingacabletie.
Note!
Equipmentforexternaldosingmustonlybeconnectedtoworkonpumppressureand
notonnetworkpressure.
