26
Connectionofexternaldosingsystems
6.2.2Machinewithoutconnectors
ConnecttheexternaldosingsystemtotheI/Oboard,whichislocatedtotherightoftheincoming
powersupply.
TheI/Oboardhasedgeconnectorsforconnectingexternaldosingsystems.
EdgeconnectorsontheI/Oboardcanbeloosenedforconnectingcables.
⑯
g.6572
11=N
18=Programrun
12=Signal1
13=Signal2
14=Signal3
15=Signal4
16=Signal5
