Technicaldata
2Technicaldata
2.1Drawing
2.1.1W575N,W585N,W5105N,W5130N
1
C
D
A
2
B
E
M
G
I
F
J
O
N
H
L
K
7
10
11
5
4
8
6
3
9
g.7649A
1
Operatingpanel
2Dooropening,W575N,W585N:⌀310mm,W5105N,W5130N:⌀365mm
3Detergentcontainer
4
Coldwater
5
Hotwater
6Waterre-use
7
Drainvalve
8Liquiddetergentsupply
9Electricalconnection
10
Steamconnection
mm
AB
C
DEF
G
H
W575N66010941131355686835801034
W585N66011571132355726836801035
W5105N72011871200365697920801119
W5130N72013261201365787920801119
mm
IJK
L
MN
O
W575N2171241014914278101199
W585N2171241015915278103199
W5105N2241241099999278105212
W5130N2241241099999278103212
