Electrolux W575N - Outputs

Connectionofexternaldosingsystems
27
6.2.3Outputs
Connectthepowersupply(e.g.24VDC)fortheexternalliquidsuppliesto9and10.Ifaninternal
powersupply(fromthemachine)isbeingused,itcanbetakenfrom1(N)andconnectedto9and
from2(L)andconnectedto10.Maxloadontheoutputs0.5A.
Signalsforexternalliquidsupplies1-5areconnectedto12-16whereconnector:
12=Signal1
13=Signal2
14=Signal3
15=Signal4
16=Signal5
⑰
g.6236B
6M146F016R016F02
Otherprograms
Signal1
-
Pre-washPre-washPre-washPre-wash
Signal2
MainwashMainwashMainwashMainwashMainwash
Signal3SoftenerSoftenerSoftenerSoftenerSoftener
Signal4
Moplastrinse
Desinfection
Pr1lastrinseMainwash
-
Signal5
BleachBleachBleachBleachBleach
