Connectionofexternaldosingsystems
25
6.2Electricalconnectionofexternaldosingsystem
Thepowersupplytotheexternaldosingsystemmustneverbeconnectedtothemachine’sincomingterminal
blockortotheedgeconnectorsontheI/O-board.
6.2.1Machinewithconnectors
ConnecttheexternaldosingsystemtoconnectionsAandBonthemachine.
ConnectthesignalcabletoBandthepowersupplytoA.
⑮
A
B
1
2
3
4
1
2
3
4
5
7
6
9
g.6598
1N
2L
4
Ground
11N
18Programrun
12
Signal1
13
Signal2
14
Signal3
15
Signal4
16
Signal5
