Electrolux W575N - Mechanical Installation

Setup
13
3.3Mechanicalinstallation
Ifthemachineisnottobemountedonabasethemachinemustbefastenedtotheoor.
Thetableshowsthecorrectdrillingpoints.
Markanddrillfourholesinthepositionsshown.
Note!
ForW5330NtwoexpanderboltsMUSTalsobettedtothefrontsectionofthemachine.If
not,largevibrationsinthemachinecabinetmayoccur.
Markanddrilltwoholes(⌀10mm)about40mmdeep(1)fortheexpanderboltsinthepositions
shown.
③
= =
G
H
I
1
1
A
F
D
E
B
C
g.0948A
mm
AB
C
DEF
G
HI
W575N685660495395115635
---
W585N725660495445115665
---
W5105N700720
575
385120695
---
W5130N785720
575
495120760
---
W5180N875750635570120855
---
W5250N950830715635125955
---
W5330N103591079069513510508101095
Afterthemachinehasbeenplacedovertheotherfourbolts,placethetwospacerwashersoverthe
twoholes.Theyshallbeplacedbetweenthemachineandfoundation.
Inserttheexpansionboltssuppliedintoalloftheholesdrilledintheoor.Fitthewashersand
nutsandtightenwell.
