33
CHOICE OF DRAIN MODE
The lower cup holder tray is supplied by the factory with a stopper, so as not to require
connection to the drain, taking advantage of its capacity only.
If you wish to connect the tray to the drain, follow the instructions in paragraph 4 below.
3
CONNECTION TO DRAIN
The machine is equipped with a rubber drainpipe, with an outer diameter of 14 mm,
about 1,5 metres long, directly connected to the removable drain tray.
This flexible hose must flow into a fixed drainage manifold, placed under the machine
support table, which must have a minimum inner diameter of 20 mm.
4
ELECTRICAL CONNECTIONS (B9 =)
The machine is equipped with an electric cable power supply around 1,5 metres in length,
with a plug at both ends.
Connect the cable both to the machine and to the network, ensuring that the electrical
properties of the latter are compatible with the specifications on the rating plate
of the device .
FILLING THE HYDRAULIC CIRCUITS (B10 ITA)
To fill the hydraulic circuits, follow the instructions in paragraph 3 of the chapter “A USE”.
5
6
