PS 9000 T Series
Setting P. Description
Analog interface Rem-SB 5 Selects how the input pin “Rem-SB” of the analog interface shall be working
regarding levels (see „3.5.4.4 Analog interface specication“ on page 51)
and logic:
• normal = Levels and function as described in the table in 3.5.4.4
• inverted = Levels and function will be inverted
Also see „3.5.4.7. Application examples“
Analog Rem-SB action 6 Selects the action on the DC output that is initiated when changing the level of
analog input “Rem-SB”:
• DC OFF = the pin can only be used to switch the DC output off
• DC AUTO = the pin can be used to switch the DC output off and on again, if
it has been switched on before at least from a different control location
3.4.3.3 Menu “Proles”
See „3.9 Loading and saving a user prole“ on page 56.
3.4.3.4 Menu “Overview”
This menu page displays an overview of the set values (U, I, P) and alarm settings as well as settings limits. These
can only be displayed, not changed.
3.4.3.5 Menu “About HW, SW...”
This menu page displays an overview of device relevant data such as serial number, article number etc., as well as
an alarm history which lists the number of device alarms that probably occurred since the device has been powered.
3.4.3.6 Menu “Communication”
Apart from settings related to the USB logging feature, all settings for the digital interface(s) on the rear side are
conguredhere.Upondelivery,thedeviceonlyfeaturesanUSBportwhichdoesn’trequireconguration.Itcan
beextendedbyanEthernet/LANportbyinstallingtheoptional3-wayinterfaceboardIF-KE4.Afterinstallationor
a complete device reset, the Ethernet port has following default settings assigned:
• DHCP: off
• IP: 192.168.0.2
• Subnet mask: 255.255.255.0
• Gateway: 192.168.0.1
• Port: 5025
• DNS: 0.0.0.0
Thosesettingscanbechangedanytimeandconguredtomeetlocalrequirements.Furthermore,thereareglobal
communication settings available regarding timing and protocols.
Submenu “IP Settings 1”
Element Description
Adr. Source DHCP: With setting DHCP the device will instantly try to get network parameters (IP, subnet
mask, gateway, DNS) assigned from a DHCP server after power-on or when changing from
Manual to DHCPandsubmittingthechangewithbuttonENTER.IftheDHCPconguration
attempt fails, the device will use the settings from Manual. In this case, the overview in screen
View settings will indicate the DCHP status as DHCP (failed), otherwise as DHCP(active)
Manual (default setting): uses either the default network parameters (after reset) or the last
user setting. Those parameters are not overwritten from selection DHCP and are thus avail-
able when switching to Manual again.
IP address Only available with setting “Manual”. Default value: 192.168.0.2
Manual setting of the device’s IP address in standard IP format (setting will be stored)
Subnet mask Only available with setting “Manual”. Default value: 255.255.255.0
Manual setting of the subnet mask in standard IP format (setting will be stored)
Gateway Only available with setting “Manual”. Default value: 192.168.0.1
Manual setting of the gateway address in standard IP format (setting will be stored)
