Pebbles
• Lay large pebble media in a random arrangement
along the entire length of the burner.
• Avoid smothering the burner channel.
• Fill in voids with medium size pebbles.
• Fill in remaining voids with small pebbles.
• Pebbles should appear as a random mix and not be
stacked more than 2 high in a few spots.
• Ensure media is not heaped in areas, spread evenly
along.
• Do not add extra media, or combine media types.
• Only the approved supplied media is to be used.
• Refer to Glen Dimplex for technical advice regarding
media.
• Do not cover pilot area.
• Do not overfill with media above the pilot cover level.
• Ensure the pilot flame is not impinged by media and
can cross light the main burner.
• Do not use any other media than as supplied and
recommended by the manufacturer.
• Use of other media may result in explosive media
which may cause injury or damage.
TYPICAL SETUP
