Remove side panels and liners to access burner locating
wingnuts.
Remove burner fixing screws (2 off at ends of burner)
Undo wingnuts to remove burner and lift burner from
position.
Lift burner and gently support.
Undo gas connection pipe at end of burner. (15mm and
16mm spanner required)
Element 900 has 2 gas tubes connected to the burner
and both must be removed to detach the burner.
