RW973 MkⅡ User Manual
17
4.7 Cash Drawer Connection
1) Make sure the printer's power switch is turned off;
2) Connect the cash drawer cable to the cash drawer interface at the rear of the printer.
Warning:
Cash drawer interface can only be connected to a voltage of 24V cash drawer device ( It can’t be
connected to the phone line, etc.)
4.8 Setting DIP switch
4.8.1 Serial interface (RS-232C)
DIP Switch 1
Switches
Functions
ON
OFF
Default
1-1
Automatic line feed
Enable
Disable
OFF
1-2
Handshake
XON/XOFF
DTR/DSR
OFF
1-3
Bit length
7 bits
8 bits
OFF
1-4
Parity check
Yes
No
OFF
1-5
Parity selection
EVEN
ODD
OFF
1-6
Baud rate selection
（bps）
Reference form 1
OFF
1-7
ON
1-8
OFF
