RW973 MkⅡ User Manual
23
5.3 Ethernet Interface
PIN NO.
Signal Name
1
TX+
2
TX-
3
RX+
4
-
5
-
6
RX-
7
-
8
-
Note: The printer is equipped with an Ethernet interface, and use the network connection
router, switch and other network communication equipment which meet RJ45 interface
standard. When connecting directly with PC, it is suggested that the cross network line in
accordance with RJ45 interface standard should be adopted.
