1. FEATURES
• Wide measuring ranges: 34 ranges for AC/DC Voltage and Current, Resistance, Capacitance, TR hFE,
Diode Test.
• 10MW Input Impedance
• Big LCD for easy reading
• Tilt Stand
2. SPECIFICATIONS
2-1 General Specifications
Display 3 1/2 LCD 0.95” height, maximum reading of 1999.
Polarity Automatic “–” sign for negative polarity.
Overrange Indication Highest digit of “1” or “–1” is displayed.
Low Battery Indication “BAT” lettering on the LCD readout.
Operating Temperature 0
O
C to 50
O
C.
less than 80% relative humidity up to 35
O
C.
less than 70% relative humidity from 35
O
C to 50
O
C.
Storage Temperature –15
O
C to 50
O
C
Temperature Coefficient 0
O
C to 18
O
C and 28
O
C to 50
O
C.
less than 0.1 x applicable accuracy specification per degree C.
Power 9V alkaline or carbon zinc battery (NEDA 1604).
Battery Life (typical) 100 hours with carbon zinc cells.
200 hours with alkaline cells.
Dimensions 3.47” (88mm) (W) x 7.52” (191mm) (L) x 1.42” (36mm) (H).
Weight Approximately 10.4oz. (300g.)
Accessories Safety Test Lead 1 pair
2-2 Measurement Ranges (Accuracy: 1 year 18
O
C to 28
O
C)
DC Voltage
Range Resolution Accuracy Maximum Input
200mV 100mV+
0.5% of rdg + 2dgt
2V 1mV +
0.5% of rdg + 2dgt
20V 10mV +
0.5% of rdg + 2dgt DC 1000V or peak AC
200V 100mV +
0.5% of rdg + 2dgt
1000V 1V +
0.5% of rdg + 2dgt
Normal Mode Rejection Ratio: Greater than 46dB at 50Hz 60Hz (1k unbalance)
