Addendum A. Power supply selection table
54
MODULE POWER SUPPLY CHOICE
AUDIO SYSTEM
OPTIMA SL255(R) / OPTIMA 255(R)V2 AC20 14VAC / 1,0A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-EL (AC20 + AC20) or AC40 14VAC / 1,5A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-J4 AC20 14VAC / 1,1A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-LPM AC20 14VAC / 1,1A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-LPM + OP-EL (AC20 + AC20) or AC40 14VAC / 1,6A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-LPM + OP-J4 (AC20 + AC20) or AC40 14VAC / 1,1A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-J4 + OP-EL (AC20 + AC20) or AC40 14VAC / 1,6A
OPTIMA SL255(R) / OPTIMA 255(R)V2 + OP-LPM + OP-J4 + OP-EL (AC20 + AC20) or AC40 14VAC / 1,7A
VIDEO SYSTEM
OPTIMA SL255RC AC20 14VAC / 1,1A
OPTIMA SL255RC + OP-EL (AC20 + AC20) or AC40 14VAC / 1,8A
OPTIMA SL255RC + OP-J4 (AC20 + AC20) or AC40 14VAC / 1,2A
OPTIMA SL255RC + OP-LPM (AC20 + AC20) or AC40 14VAC / 1,2A
OPTIMA SL255RC + OP-H4 (AC20 + AC20) or AC40 14VAC / 1,3A
OPTIMA SL255RC + OP-H4 + OP-VP4 (AC20 + AC20) or AC40 14VAC / 1,4A
OPTIMA SL255RC + OP-H4 + OP-J4 (AC20 + AC20) or AC40 14VAC / 1,4A
OPTIMA SL255RC + OP-H4 + OP-EL (AC20 + AC20) or AC40 14VAC / 2,0A
OPTIMA SL255RC + OP-H4 + OP-LPM (AC20 + AC20) or AC40 14VAC / 1,4A
OPTIMA SL255RC + OP-LPM + OP-EL (AC20 + AC20) or AC40 14VAC / 1,8A
OPTIMA SL255RC + OP-LPM + OP-J4 (AC20 + AC20) or AC40 14VAC / 1,2A
OPTIMA SL255RC + OP-J4 + OP-EL (AC20 + AC20) or AC40 14VAC / 1,8A
OPTIMA SL255RC + OP-LPM + OP-J4 + OP-EL (AC20 + AC20) or AC40 14VAC / 1,9A
OPTIMA SL255RC + OP-H4 + OP-J4 + OP-EL (AC20 + AC20) or AC40 14VAC / 2,0A
OPTIMA SL255RC + OP-H4 + OP-J4 + OP-LPM (AC20 + AC20) or AC40 14VAC / 1,4A
OPTIMA SL255RC + OP-H4 + OP-EL + OP-LPM (AC20 + AC20) or AC40 14VAC / 2,0A
OPTIMA SL255RC + OP-H4 + OP-VP4 + OP-LPM (AC20 + AC20) or AC40 14VAC / 1,5A
OPTIMA SL255RC + OP-H4 + OP-VP4 + OP-J4 (AC20 + AC20) or AC40 14VAC / 1,5A
OPTIMA SL255RC + OP-H4 + OP-VP4 + OP-EL +OPJ4 (AC20 + AC20) or AC40 14VAC / 2,2A
OPTIMA SL255RC + OP-H4 + OP-VP4 + OP-EL + OP-LPM (AC20 + AC20) or AC40 14VAC / 2,2A
OPTIMA SL255RC + OP-H4 + OP-VP4 + OP-J4 + OP-LPM (AC20 + AC20) or AC40 14VAC / 1,6A
OPTIMA SL255RC + OP-H4 + OP-VP4 + OP-EL + OP-J4 + OP-LPM (AC20 + AC20) or AC40 14VAC / 2,3A
OP-VR4 (centralized power supply 4 videomonitors) DR-30-15 15VDC / 2A
OP-VR4 (local power supply for 4 videomonitors) DC15-1,2A 15VDC / 0,1A
OP-VM2 (single videomonitor local power supply) DC15-1,2A 15VDC / 0,6A
OP-VM4 (single videomonitor local power supply) DC15-1,2A 15VDC / 0,4A
OP-VM7 (single videomonitor local power supply) DC15-1,2A 15VDC / 0,4A
DESCRIPTION
OPTIMA SL255(R) / OPTIMA 255(R)V2 – Digital entry phone panel for multi-entry system(SLAVE)/ single entry system
OPTIMA SL255RC – Digital entry phone video panel for multi-entry system(SLAVE)
OP-LPM – small list of tenants module (to print)
OP-VM2 videomonitor 2,4”
OP-VM4 videomonitor 4”
OP-VM7 videomonitor 7”
AC20 – 14VAC 20VA power supply
AC40 – 14VAC 40VA power supply
VOLTAGE/
CURRENT
OP-J4 – four-button selection module
OP-EL – electronic list of tenants
OP-H4 – four-channel communication module
OP-VP4 – 4 – input video signal distributor
OP-VR4 – 4 – channel video signal distributor
CAUTION! Table selection of power supplies not included the issue of voltage drops on the supply lines.
