24 FAP User
18.9 APPENDIX 9 – POINT TYPES
The following table shows the shortened strings related to the point types and the relevant explanation. These strings
can be found in the messages of alarm events, faults and exclusions related to the point.
Point type
(shortened)
Meaning
SM Smoke detector
HT Heat detector
MU Output module
MC Concentrator module
MN Manual push button
GS Gas detector
LN Linear detector
SH Smoke/Heat detector
LI Latch input module
PI Pulse input module
XS Smoke/Heat/Gas detector
TB Bathroom Call Cord
CI 4-20 mA current input module
IS Latch input module with siren output
18.10 APPENDIX 10 – POINT ATTRIBUTES QUALIFIER
The visualization of an event of alarm/fault/exclusion/inclusion of a point contains a qualifier Q of the possible
attributes of the point.
The meaning of this qualifier is reported in the table below:
Qualifier Meaning
R Point with Clear Delay function enabled
M Point with Global Alarm function enabled
B Point with both Clear Delay and Global Alarm functions enabled
d Manual Push Button degraded
r Manual Push Button degraded with Clear Delay function enabled
m Manual Push Button degraded with Global Alarm function enabled
b Manual Push Button degraded with Clear Delay and Global Alarm functions enabled
18.11 APPENDIX 11 – ALARM TYPES
The following table reports the alarm types signalled by a point.
Alarm type Meaning
1 Alarm for smoke
2 Alarm for temperature
3 Alarm for smoke/temperature
4 Alarm for manual push button
5 Alarm for input 1
6 Alarm – undefined cause because of a communication problem with the point
7 Alarm for gas
8 Alarm from conventional detection circuit
9 Alarm for overtaking the current threshold of the 4-20 mA module
