18.12 APPENDIX 12 – ZONE TYPES
The table below reports the meaning of the shortened strings containing the information on the zone type.
Zone type Meaning
FR Fire alarm zone type
TN Technological zone type
18.13 APPENDIX 13 – ERROR CODES FOR PRINTER MODULE
If a fault relevant to the printer occurs during the monitoring phase, the user is notified with the following message:
FAULT PRINTER XX
XX = error code
The table below reports the error codes of the printer module and the relevant explanation:
Code Fault
1 Printer not connected
2 Missing paper
3 Printer continuously busy
4 The printer module does not answer to the command
5 Printer module: program supervision error (1)
6 Printer module: non volatile memory access error
7 Printer in fault (generic error)
(1) Please, contact the ELKRON Customer Service.
18.14 APPENDIX 14 – PS2 KEYBOARD MAPPING
The table below shows the list of the PS2 keys used and their mapping with the correspondent key in the internal
keyboard.
PS2 key Function
ESC ESC
F1 RESET
F2 SILENCE REARM SIREN
F3 INCREASE DELAY
F4 SKIP DELAY
F5 INCLUDE EXCLUDE
F6 MASTER ALARM
F7 MENU
F8 ACK
ENTER OK
DEL Char cancellation (equivalent to LEFT arrow)
Directional keys (UP, DOWN, LEFT, RIGHT) Directional keys (UP, DOWN, LEFT, RIGHT)
- (numerical keypad) Decrease LCD sharpness
+ (numerical keypad) Increase LCD sharpness
SHIFT Enable uppercase letters
CAPS LOCK Permanently enable upper case letters
