Elmo MO-1 Quick Start Guide

5
③Connecting to a projector or a monitor
④Connecting to a PC
RGB cable (Option)
HDMI cable (Option)
To wall outlet
●Connecting with an RGB cable ●Connecting with an HDMI cable
To projector/monitor
●Connecting to the USB port
Micro HDMI(Type D)
To PC
Mini-B-Type connector
USB2.0 cable
AC Adapter
AC cord
connector
To projector/monitor
AC Adapter
To wall outlet
To wall outlet
AC Adapter
AC cord
AC cord

Elmo MO-1 Specifications

General

Product color	Pink
Built-in microphone	Yes
Sensor type	CMOS
White balance	Auto, Manual
Optical sensor size	1/3.2 \
Effective sensor resolution	5 MP
Supported graphics resolutions	-
Digital zoom	8 x
Shooting area (WxD)	257 x 342 mm
VGA (D-Sub) input ports	1
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Cables included	AC, USB

Weight and Dimensions

Depth	226 mm
Width	101 mm
Height	338 mm
Weight	550 g
Dimensions folded (WxDxH)	101 x 226 x 28 mm
