Elmo MO-1 Quick Start Guide

7
・Adjusting the brightness
・Operating panel
Mark Name Function
Lamp
To turn the lamp ON/OFF
Image Rotation
Camera Live image :Rotates by 180°
Camera Still image: Rotates counterclockwise by 90°.
Image Freeze
/Capture
To pause the camera image by pressing this button for a
short moment (less than 1 second). Press this button
again to restart.
To save a still image to the SD card by pressing this
button for long (more than 1 second).
Menu To show/hide the menu on the screen.
Image Selection To switch the output video.
Brighten
Darken
Lamp
Rotation
Image Freeze
/
Ca
p
ture
Menu
Image Selection

Elmo MO-1 Specifications

General

Product color	Pink
Built-in microphone	Yes
Sensor type	CMOS
White balance	Auto, Manual
Optical sensor size	1/3.2 \
Effective sensor resolution	5 MP
Supported graphics resolutions	-
Digital zoom	8 x
Shooting area (WxD)	257 x 342 mm
VGA (D-Sub) input ports	1
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Cables included	AC, USB

Weight and Dimensions

Depth	226 mm
Width	101 mm
Height	338 mm
Weight	550 g
Dimensions folded (WxDxH)	101 x 226 x 28 mm
