RS-232C
96
Setting Up
q Connect this product to a PC with an RS-232C cable.
When using an RS-232C cable available on the market, make sure that pin connections are the same as
below.
To protect this product and the PC, be sure to turn OFF the power supply to all units before starting the
connection work.
w Start the PC, and set the communication mode of the RS-232C to the communication
mode of this product.
For the information how to set the communication mode of the RS-232C, refer to the instruction manual of
the PC.
e Start the PC program to operate this product.
r Control through the RS-232C will start.
For communication control, be sure to take the above steps for settings.
This product can be controlled from a PC connected to this product through the RS-232C
terminal [RS-232C].
Cable Connection
To Next Page
