Elmo P10 - General

ENGLISH
SPECIFICATIONS
102
■ General
8 SPECIFICATIONS
Item Specifications
Power source 12VDC (AC adapter: 100 ~ 240VAC)
Power consumption 30W (AC adapter included)
Outside dimensions 377×482×180mm (14.8×19.0×7.1 in) (When folded)
377×482×582mm (14.8×19.0×22.9in) (When set up)
Weight Approx. 4.7kg (10.4 lbs) (Main body only)
Input selection Main body / External one system
Output terminal DVI output DVI-D 24P connector, female ×1
RGB output Mini DSUB 15P connector, female ×1
Composite video RCA pin jack / 750Ω unbalanced ×1
output (NTSC/PAL)
S-video output Mini DIN 4P connector / 750Ω×1
unbalanced (NTSC/PAL)
Input terminal RGB input Mini DSUB 15P connector, female ×1
Ext. control terminal RS-232C Dsub 9P connector, male ×1
USB (2.0 compliant) Type B receptacle ×1
Memory interface SD card slot
