ELNA Transforma - Adjustment of Coupling Device at Flywheel; Bent Thread Guides

37

19. Adjustment of Coupling Device at Flywheel
Couplingdevicewillfunctionproperlywhenpointofcouplingknobscrewisatadistanceofabout1/8"fromthe
nearestoutsidelugofthecouplingstop,whenthecouplingknobisfirmlytightened.Ifpointofcouplingknob
screwtouchestheoutsidelugofthecouplingstopbefore,couplingknobisfullytightened.Removecoupling
knobanddisplacecouplingstopinaclockwisedirectionuntiltheaforementionedrequirementismet.
20. Bent Thread Guides
TherearethreeThreadGuidesonthefrontcover,twoatthe
topandoneatthebottom.Iftheybecomebenttheymaynot
guidethethreadasintended.
TheguidesareheldinplacebyaSetScrew.
Caution!Toavoiddamagingthefrontcover,removethe
ThreadGuidebeforeattemptingtostraightenit.
TheeasiestwaytoaccesstheSetScrewsistoremovethe
twofrontcoverhingescrewsandremovethecover.
LoosentheSetScrewandremovethethreadguide.
Caution!Becarefulnottomarthethreadguidewiththe
toolsyouareusing.Thiscouldleadtothreadsnags.
Using2pairofpliersorabenchvisegrasptheThreadGuide
oneithersideofthebendasclosetothebendaspossible.
Gentlystraightenthebend.TheThreadGuideshouldbe
straightexceptfortheloopattheend.
InserttheThreadGuidebackintothefrontcoverandtighten
theSetScrew.
Reattachthefrontcoverhinge.

