- 105 -
U101 OTP/MTP MCU WT62P1 7A0DH Ver1.0 ET1787C-BALLY 384900050074
RL501 RELAY 1P2T 12V JS1-12V AJS-1311 NAIS 432001200700
RL601 RELAY 2P1T 12V FTR-F4AK012T 432002101000
PCB MAIN CEMI-1 T1.6/1oz 246x249mm REV.01 ET15/17 441000470100
U101A IC SOCKET 40PIN 2.54mm D=15.24 450050404000
F601A CLIP FUSE 5X20mm t=0.4mm 450065200200
TB2 GT PIN R=1.56mm l=13mm 452001561300
R525A,R525B GT PIN R=2.36mm L=20mm 452002362000
T12 BASE PIN 2.0mm 2PIN 452072000200
T10,T8 BASE PIN 2.5mm 2PIN 452102500200
T3 BASE PIN 2.5mm 5PIN 452102500500
T7 BASE PIN 5-7.5mm 2PIN A1561WV2-2P 452205750200
T5 BASE PIN 8-10mm 4PIN JS-1122-4 452258100400
DOWNLOAD PIN HEADER 2.54mm 2PINX1ROW 452802500200
T11A PIN HEADER L=4.0mm 2.54mm 6PINX1ROW RA 452862500600
T9A PIN HEADER L=4.0mm 2.54mm 13PINX1ROW RA 452862501300
T4A BASE PIN 2.0mm 6PIN RA 453012000600
F601 FUSE GLASS TUBE 5TT3 BEL 3A 250V S-B 5*20 UL/CSA 471100030000
F602,J21 FUSE PICO 2A 125V F-B 251 471503020000
X101 CRYSTAL 12MHZ (HC-49/U) 473000120000
U301T SILICON INSULATOR TO-220 13mmX18.5mm 475000100100
Q602P SILICON RUBBER TO-2025A 20mmX25mmx0.45mm 475000200200
Q602N TRANSISTOR COVER TR-09 475050000100
W502 WIRE 1500#18 BLK SRA/ST0(SLEEV) L=180mm 512006401800
G2 WIRE SVF1/1032#22 WHITE L=330 523018593300
S101 WIRE ASSY AC CONNECTOR 3PIN ELO 531000301100
T6 WIRE ASS'Y 2651#28 2mm-6/2mm-6 L=240mm 531000601200
T4 WIRE ASS'Y 2651#28X6C 6P-6P(3,4 CROSS)L=1000mm 531000601900
T2 WIRE ASSY L=330mm 2mm-9/2mm-9 2651#28+CORE 531000900900
W202 SIGNAL CABLE UL20279X13C DSUB-15/XHP-5-7 L=280mm 531310200300
T1 JUMPER WIRE PITCH=5mm 531400005000
D803,D804,J01,J13, JUMPER WIRE PITCH=7.5mm 531400007500
J15,J16,J31,J37,J38,
J39,J40,J42,J43,J47,
L611,R148,R149,R153,
R574,R803
J02,J06,J10,J11,J17, JUMPER WIRE PITCH=10mm 531400010000
J18,J19,J22,J25,J26,
J29,J30,J32,J33,J48,
L101,L508,R613,R624
J12,J20,J23,J24,J34, JUMPER WIRE PITCH=12.5mm 531400012500
J36,R301,R506,R534
J04,J07,J08,J09,J14, JUMPER WIRE PITCH=20mm 531400020000
L504
