Elo TouchSystems ET1587C User Manual

- 71 -
ET 17”
ET1787C -4SWA-1 , ET1787C-ONWA-1, ET1787C-4SJA-1, ET1787C-4UWA-1,
ET1745C -4SWE-1, ET1745C-4UWE-1
Common Parts
571717303000D (ET17 NEW M/B RIVET ASSY)
571909304000A (ET17/19 CRT BOARD ASSY)
571717303000D (ET17 NEW M/B RIVET ASSY)
CIRCUITREF DESCRIPTION PART NO.
R220,R502,R623 RES CF 1/8W 10ohm J T 211003010000
R134,R135,R136,R137, RES CF 1/8W 100ohm J T 211003010100
R146,R147,R223,R224,
R225
R104,R106,R110,R112, RES CF 1/8W 1K J(+/-5%) T 211003010200
R117,R131,R133,R138,
R207,R226,R511,R519,
R522,R523,R527,R562,
R565,R621,R635,R638
R142,R228,R310,R529, RES CF 1/8W 10K J(+/-5%) T 211003010300
R537,R631,R807
R202,R227,R231 RES CF 1/8W 100K J T 211003010400
R229 RES CF 1/8W 10M J T 211003010600
R309 RES CF 1/8W 13K J T 211003013300
R156,R308,R520,R526 RES CF 1/8W 1.5K J T 211003015200
R212 RES CF 1/8W 15K J T 211003015300
R625 RES CF 1/8W 150K J T 211003015400
R210 RES CF 1/8W 1.8K J T 211003018200
R501,R503,R619,R627 RES CF 1/8W 18K J T 211003018300
R515 RES CF 1/8W 200K J T 211003020400
R230 RES CF 1/8W 2M J T 211003020500
R103,R111,R113,R114, RES CF 1/8W 220ohm J(+/-5%) T 211003022100
R122,R123,R124,R125,
R126,R127,R128,R143,
R144,R200,R205,R206,
R208,R222,R554
R159,R232 RES CF 1/8W 2.2K J T 211003022200
R211 RES CF 1/8W 22K J T 211003022300
R145,R626 RES CF 1/8W 2.4K J T 211003024200
R541 RES CF 1/8W 24K J T 211003024300
R155 RES CF 1/8W 2.7K J(+/-5%) T 211003027200
R105 RES CF 1/8W 27K J T 211003027300
R540 RES CF 1/8W 300K J T 211003030400
R539 RES CF 1/8W 330ohm J T 211003033100
R508,R516,R628 RES CF 1/8W 33K J T 211003033300
