Elo TouchSystems ET1587C - Page 134

- 133 -
C535 CAP PLASTIC 0.22uF J 250V MPP 15 281602122400
C536 CAP PLASTIC 0.39uF J 250V MPP 20 281602139400
C534 CAP PLASTIC 0.43uF J 400V MPP 20 281603143400
C601 CAP X 0.22uF AC 250V/300V 22.5 291000022400
C610,C615 CAP Y1 4700PF AC 250V (AH) 291250047200
L505 LINEARITY COIL 0A 6uH ET19 321000002300
L507 COIL CHOKE 17uH 321200001300
L510 COIL CHOKE 3mH 321200003500
L602 AC LINE FILTER 35mH 321300100700
G2B CORE 1-T-20x10x10-EM2 321500002300
L608 COIL BEAD 6mmX10mm 321503000400
J05,L102,L501,L502, COIL BEAD 3.5mmX6mm 321503001000
L603,L606,L609,L610,
L612
J28,J28A,L503 CORE BEAD 3.5X9X0.8 321503001300
L601,L601A CORE RING 35uH 321700001000
D202 COIL PEAKING 10uH K T (EC24) 323053010000
T601 TRANSFORMER POWER UD1 331000002000
T501 TRANSFORMER FBT ET17 331100002300
T503 TRANSFORMER COUPLING 331250000700
T504 TRANSFORMER FOCUS ET 331250000800
T502
TRANSFORMER H-
DRIVER
L:53uH+/-20%,LK:160uH 331300000800
Q608 TRANSISTOR 2SA673AC 361103067300
Q201,Q503,Q506,Q515 TRANSISTOR 2SA733P 361103073300
Q610,Q611 TRANSISTOR 2SA1020Y T 361103102000
Q508 TRANSISTOR 2SC5387(HFE) 361300538700
Q101,Q202,Q203,Q204, TRANSISTOR TAPING H945P / C945P 361303094500
Q504,Q511,Q514,Q523,
Q524,Q525,Q527,Q603,
Q606,Q607
Q609 TRANSISTOR 2SC1213AC T 361303121300
Q507 TRANSISTOR 2SK941 361500094100
Q501 TRANSISTOR SSS6N60A 361550066000
Q602 TRANSISTOR SSS7N80A 361550078000
Q513 TRANSISTOR BF420 T 361603042000
Q502 TRANSISTOR BF423 T 361603042300
Q517,Q518 TRANSISTOR IRFS640A 361700064000
Q516
TRS. N-MOSFET
FAIRCHILD
IRFS740B 10A/400V TO220F 361700074000
D502,D508 DIODE UF4005G JIT 1A/600V 50-75ns T 371203100600
D619,D619B DIODE UF4007 JIT 1A/1000V 50-75ns T 371213101000
D101,D102,D204,D503, DIODE 1N4148(1A/75V) T 371303107500
D505,D507,D512,D610,
D613,D618
D509 DIODE (2A/400V) UGP20G/SF20GG KINK P=20 371721200400
