T704 GT PIN R=2.36mm L=14mm 452002361400
T701 BASE PIN 2.5mm 7PIN R/A 452112500700
T703 BASE PIN 2.0mm 6PIN RA 453012000600
T702 BASE PIN 2.0mm 9PIN RA 453012000900
C728,K701,K702,K703, SPARK GAP 1.2KV 473500312200
K704
J702,J703,J710 JUMPER WIRE PITCH=7.5mm 531400007500
J701,J705,R719,R720, JUMPER WIRE PITCH=10mm 531400010000
R721
J706,J707,J708,J711 JUMPER WIRE PITCH=12.5mm 531400012500
J704 JUMPER WIRE PITCH=15mm 531400015000
J709 JUMPER WIRE PITCH=20mm 531400020000
ET17/19 CRT BOARD
ASSY
ET17/19 571909304000A
5S04 VIDEO SHIELDING GAME 720305200101
U703N HEAT SINK 60LX24WX30.5H 13mm 730401900301
U703M SCREW CTTWE 3.0x8 Zn 773656050201
571909402000A (ET19 CPT CRT iTOUCH ASSY)
CIRCUITREF DESCRIPTION PART NO.
V501 CRT 0.25mm CPT M46AJM53X76(EL) (Asahi) 411902501504
V501E ALU TAPE 3cmX20cm ELECTRIC 474363002000
WIRE ASSY ELO 012525 ET19 531001201800
ET19 CPT CRT iTOUCH ASSY ET19 571909402000A
ADHESIVE DOUBLE TAPE ELO W=3.14mm L=33M/R 820303300101
GEL 602-GEL ELO 10ml 830100200301
UV GLUE Elo (6-20288) 830101400101
UV INK 160173 ELO (M16979-05-N) 700g 830200100101
571909303000H (ET19 M/B RIVET BALLY ASS)
CIRCUITREF DESCRIPTION PART NO.
R220,R502,R623 RES CF 1/8W 10ohm J T 211003010000
R134,R135,R136,R137,
R146,R147,R223,R224,
R225
R104,R106,R110,R112, RES CF 1/8W 1K J(+/-5%) T 211003010200
R117,R131,R133,R138,
R207,R226,R511,R519,
R522,R523,R527,R562,
R563,R565,R621,R635,
R638
R142,R228,R310,R529, RES CF 1/8W 10K J(+/-5%) T 211003010300
R537,R631,R807
R202,R231 RES CF 1/8W 100K J T 211003010400
R229 RES CF 1/8W 10M J T 211003010600
R227 RES CF 1/8W 120K J T 211003012400
R309,R503,R508 RES CF 1/8W 13K J T 211003013300
R156,R308,R520,R526 RES CF 1/8W 1.5K J T 211003015200
R212 RES CF 1/8W 15K J T 211003015300
