- 160 -
Q517,Q518 TRANSISTOR IRFS640A 361700064000
Q516 TRS. N-MOSFET FAIRCHILD
IRFS740B 10A/400V TO220F
361700074000
D502,D508 DIODE UF4005G JIT 1A/600V 50-75ns T 371203100600
D619,D619B DIODE UF4007 JIT 1A/1000V 50-75ns T 371213101000
D101,D102,D204,D503, DIODE 1N4148(1A/75V) T 371303107500
D505,D507,D512,D610,
D613,D618
D509 DIODE (2A/400V)
UGP20G/SF20GG KINK P=20
371721200400
Q509 DIODE BY329X-1500S 5A/1500V 371960501504
D201,D513,D612,D801 DIODE 1A/100V T FR102/PR1002 372153100100
D516,D611 DIODE 1A/400V T FR104/PR1004 372153100400
D609 DIODE 1A/600V T PR1005 372153100600
D301 DIODE 1A/1KV T FR107/PR1007 372153101000
D617 DIODE HER304 3A/300V KINK
P=20
372201300325
D615 DIODE HER305 3A/400V KINK
P=20
372201300425
D621 DIODE 3A/800V KINK P=20 UF3006 372201300824
D622 DIODE 3A/1KV KINK P=20 UF3007 372201301024
D517 DIODE 1A/100V T HER102/UF1002 372203100100
D616,D624 DIODE 2A/400V T HER205/UF2004 372203200400
D608 DIODE 2A/800V T HER207/UF2006 372203200800
D601 DIODE BRIDGE PBL406/KBL406(4A/800V) 373000400800
LED1 LED D=3mm GREEN L-34GD 373502100300
D605 DIODE ZENER HITACHI 1/2W HZ4C3 DO-35 T 375003043300
D610A,R804 DIODE ZENER 1/2W HZ5C2 5.0V-5.2V T 375003053200
D510 DIODE ZENER 1/2W HZ15-2 T 375003150200
D619A DIODE ZENER 1/2W HZ20-3 20.2-21.1 T 375003200300
D515 DIODE ZENER 1/2W HZ36-2 T 375003360200
D504 ZENER DIODE 1W Z150A 150V 10% T 375503015100
U301 IC TDA8172 vertical process 381300017210
U201 IC TDA9113 381400011310
U602 IC UC3842AM 8 382500084227
U501 IC HA17812 3 382600081201
Q505 IC TL431 382660043144
U603 IC LM2940 3 382700094005
U102 IC AT24C04 8 384300040425
U103 IC WT6804 16 384300080416
U101 OTP/MTP MCU WT62P1 79F3H Ver1.0 ET1987C-BALLY 384900050073
RL501 RELAY 1P2T 12V JS1-12V AJS-1311 NAIS 432001200700
RL601 RELAY 2P1T 12V FTR-F4AK012T 432002101000
PCB MAIN CEMI-1 T1.6/1oz
246x249mm REV.01 ET15/17
441000470100
U101A IC SOCKET 40PIN 2.54mm D=15.24 450050404000
F601A CLIP FUSE 5X20mm t=0.4mm 450065200200
TB2 GT PIN R=1.56mm l=13mm 452001561300
To Next Page
