- 186 -
1P01 EPE FOAM (L) ET19 FLAT 810701700201
1P02 EPE FOAM (R) ET19 FLAT 810701800201
1P11 CARTON ET19F ELO 820109300101
V501E,V501F TAPE MYLAR 3M#898 19mmX50M 820300400101
END UNIT LABEL (INNE) 820600500101
BLANK LABEL (50X35) 820604200101
BLANK BARCODE LABEL ELO 100X100 820606200101
1P06 PALLET WOODEN 1145X1210X120mm 821601800101
GLUE HOT MELT CLEARSTICK ELO (160108) 830100300101
LOCTITE ELO (262) 830100400101
6F12 FLUOROSYL 998307 FSD2500-16 ELO 830200300101
571909402000G (ET19F CPT TF iTOUCH ASSY)
CIRCUITREF DESCRIPTION PART NO.
V501 CRT M46AJS53X76(EL) 19 411902501204
V501E ALU TAPE 3cmX20cm ELECTRIC 474363002000
WIRE ASSY ELO 012525 ET19 531001201800
ET19F
ADHESIVE DOUBLE TAPE ELO W=3.14mm L=33M/R 820303300101
GEL 602-GEL ELO 10ml 830100200301
UV GLUE Elo (6-20288) 830101400101
UV INK 160173 ELO (M16979-05-N) 700g 830200100101
571909304000A (ET17/19 CRT BOARD ASSY)
CIRCUITREF DESCRIPTION PART NO.
R711,R712,R713,R714, RES CF 1/8W 100ohm J T 211003010100
R736
R710,R737 RES CF 1/8W 1K J(+/-5%) T 211003010200
R707,R735 RES CF 1/8W 10K J(+/-5%) T 211003010300
R708,R709,R722,R723, RES CF 1/8W 220ohm J(+/-5%) T 211003022100
R724
R729,R730,R731 RES CF 1/8W 220K J T 211003022400
R704,R705,R706 RES CF 1/8W 330ohm J T 211003033100
R726,R727,R728 RES CF 1/8W 56ohm J T 211003056000
R701,R702,R703 RES CF 1/8W 75ohm J T 211003075000
R738 RES CF 1/4W 100ohm J T 211103010100
R732,R733,R734 RES CF 1/4W 56ohm J T 211103056000
R742 RES CF 1/2W 100K J T 211203010400
R741 RES MOF 1W 3.3ohm J 12.5 212501033800
C704 CAP ELEC 100uF M 10V 105 TAPING 261201310100
C708 CAP ELEC 22uF M 10V 105 T 261201322000
C710 CAP ELEC 10uF M 50V 105 T (20%) 261205310000
C722,C727 CAP ELEC 2.2uF M 100V 105 TAPING 261208322800
C716,C717,C718 CAP ELEC 1uF M 100V 105 NK T 261328310800
C709 CAP CERAMIC 100PF K 50V Y5P T 272001310100
C705 CAP CERAMIC 220PF K 500V Y5P T 272004322100
C724 CAP CERAMIC 560PF K 500V Y5P T 272004356100
