- 25 -
Deflection
yoke
STEP-4
B R R B
Tilting the yoke up Tilting the yoke down
Rear view of the CRT
Deflection
yoke
STEP-5
R B B R B R RB
Tilting the yoke left Tilting the yoke right
Rear view of the CRT
Differential
coil
STEP-6
B R
R B
Differential
resistor
VR-YV
( V)
STEP-7
R B
B R
B R
R B
Deflection
yoke
Wedge
Wedge
