- 32 -
yc:y coordinate at any other point
Display area : 317 ×237mm for Atronic 17” mode 4 and Bally 17” mode1~7.
Display area : 356 ×264mm for Bally 19” mode 1~7.
Display area : 358 ×268mm for SEGA 19” mode 8~9.
<Conditions>
Display image : White flat field
Luminance : 25 FtL at the center of display area
Display area : 270 ×202mm for 15”
Display area : 300 ×225mm for 17”
Display area : 350 ×262mm for 19”
Display area : 317 ×237mm for Atronic 17” mode 4 and Bally 17” mode1~7.
Display area : 356 ×264mm for Bally 19” mode 1~7.
Display area : 358 ×268mm for SEGA 19” mode 8~9.
2.6.9 Jitter
Invisible at a distance of 60 cm from CRT surface.
