- 63 -
ET1587C-ONWA-1
CIRCUITREF DESCRIPTION PART NO.
V501B
COIL DEGAUSSING 智丞
R=18.5ohm L=300mm 321400001307
V501C COIL ROTATION 300 TURNS L=200mm 321760000200
V501 CRT (Asahi) 0.28mm M36AJA93X46 411502803904
5S04M GASKET 20X20X20 474400000300
V501D WIRE ASSY 1015#22 SGF-STO L=170/110+SLEEVE 531000203300
W201 SIGNAL CABLE 6715008201 DSUB-15PX2 1830mm HP 531311800800
V501CA,V501CC CABLE TIE PLT1M L=100mm 7130K12 532000001000
V501A CRT GROUNDING WIRE 0.12/64 1015#22 ET15 532500005400
ET15 NEW M/B ASSY RIVET ET15 571527303000B
ET15 CRT BOARD ASSY ET15 571527304000A
6F08S KNOB ET17 ATRONIC 711102000101
6F01,6F02 TOP CHASSIS ET1 15 720113000101
6F10 BRACKET REAR (ELO) 15 720114500102
6F06 BRANCE ANGLE LEFT (ELO) 15 720114600101
6F07 BRANCE ANGLE RIGHT (ELO) 15 720114700101
6F05 BRACKET MAIN BOARD ET1 (ELO) 720115100202
6F08 BRACKET CONTROLLER ET1 (ELO) 720115200201
6F03,6F04 BRANCE ET15 720134000101
6F22 FENCE OSD ET1 720139800101
V501P CAUTION LABEL 25KV 740202400101
6B01M HI POT LABEL 740202700101
6F08T VR LABEL ET1 KNOB 740402900101
BLANK B/C LABEL T=0.05 76X57.6 741200700101
6F07T RUBBER PAD ET1 760201600101
6F22A SCREW CPMSP M3.0x6 Zn-Cc 771176040201
5S05M,5S06M, SCREW CPMSP 4.0X8 Zn 771177050101
6F05M,6F06M,
6F07M,6F10M
6F03M,6F04M SCREW CPMSP M6X8 Zn 771179050101
6F08M,6F08P, SCREW CPTSPB 3.0x8 Zn-Cc 771376050201
6F08Q
6F01M,6F02M SCREW CHTM M6X15 Zn 775119080101
1P21 PE BAG 525X425X750X0.04T 810201100201
1P11B DRIER SILICA GEL ELO 15 (40g) 810400300101
1P01 EPE FOAM (L) ET1 15 810701100101
1P02 EPE FOAM (R) ET1 15 810701200101
1P22 ZIP BAG R0273A14 210X295X0.04t 811200400101
1P11 CARTON ET1 15 ELO 820105300101
V501E,V501F TAPE MYLAR 3M#898 19mmX50M 820300400101
END UNIT LABEL (INNE) 820600500101
BLANK LABEL (50X35) 820604200101
BLANK BARCODE LABEL ELO 100X100 820606200101
2P03 QUICK START GUIDE ET1 821103400103
2P02 GUIDE TOOLS CD ELO REV.J 821500101101
1P06 PALLET ET15 WOODEN 100X96X13cm 821600900102
To Next Page
