- 66 -
ET1545C-4UWE-1
CIRCUITREF DESCRIPTION PART NO.
V501B
COIL DEGAUSSING 智丞
R=18.5ohm L=300mm 321400001307
V501C COIL ROTATION 300 TURNS L=200mm 321760000200
CONTROLLER IT USB ELO 714259-000 474000000400
5S04M GASKET 20X20X20 474400000300
T10A WIRE ASS'Y 012379 XHP2-10 1007#26 L=255mm 531000200700
V501D WIRE ASSY 1015#22 SGF-STO L=170/110+SLEEVE 531000203300
W204 SIGNAL CABLE 012572 USB CABLE B-B 380mm BK 531300300200
W201 SIGNAL CABLE 6715008201 DSUB-15PX2 1830mm HP 531311800800
W203 SIGNAL CABLE CORE 012571 USB CABLE A-B 1830mm HP 531311802200
V501CA,V501CC CABLE TIE PLT1M L=100mm 7130K12 532000001000
V501A CRT GROUNDING WIRE 0.12/64 1015#22 ET15 532500005400
W001 AC POWER CORD 918850-000 1.5M BK UL MTW UNSHIELD 533000120500
W002 AC POWER CORD D57513-000 1.5M BK VDE MTW UNSHIELD 533000320800
ET15 NEW M/B ASSY RIVET ET15 571527303000B
ET15 CRT BOARD ASSY ET15 571527304000A
ET15 CRT iTOUCH ASSY ET15 571527402000A
6F12 MINI BEZEL ELO 15 GE LEXAN 920-116 710101100201
6F22 SQUARE BEZEL ET1545C C57638-000 710103000101
6F08S KNOB ET17 ATRONIC 711102000101
6F08N,6F08R PCB SUPPORT R0180L2000 PINGOOD SCB-5 (ET1) 711901900101
6F18F PLASTIC WASHER W8X4.1X2t 712001600101
T10B MOVABLE TIE PINGOOD (BST-6A) 712100800101
6F18D SNAP CLIP SN-01G 712301500101
6F18E SNAP CLIP SN-01GB 712301600101
6F01,6F02 TOP CHASSIS ET1 15 720113000101
6F10 BRACKET REAR (ELO) 15 720114500102
6F06 BRANCE ANGLE LEFT (ELO) 15 720114600101
6F07 BRANCE ANGLE RIGHT (ELO) 15 720114700101
6F08 BRACKET CONTROLLER ET1 (ELO) 720115200201
6F11 ADJUSTER EAR ELO 15" 720116800102
6F15,6F16 BRACKET-ITEM 2 ET17 SD502708 ITEM 2 720132700101
6F03,6F04 BRANCE ET15 720134000101
6F13,6F14 BRACKET-ITEM 1 ET15 SD502709 ITEM 1 720134900101
6F17 BRACKET COVER-ITEM 3 ET15 SD502709 ITEM 3 720135100101
6F18 TOP BRACKET-ITEM 4 ET15 SD502709 ITEM 4 720135200101
6F19 MAIN BOARD COVER-ITEM 6 ET15 SD502709 ITEM 6 720135400101
6F20 BRACKET RIGHT-ITEM 7 ET15 SD502709 ITEM 7 720135500201
6F21 BRACKET LEFT -ITEM 8 ET15 SD502709 ITEM 8 720135600101
V501P CAUTION LABEL 25KV 740202400101
6B01M HI POT LABEL 740202700101
WARNING LABEL D.I FOR CARTON (ELO) 740203200101
6F10A CAUTION LABEL 28KV 740203400101
V501Q CRT LABEL FOR CPT ASAHI 740402400101
To Next Page
