Elo TouchSystems ET1587C User Manual

- 77 -
T1 JUMPER WIRE PITCH=5mm 531400005000
D803,D804,J01,J13, JUMPER WIRE PITCH=7.5mm 531400007500
J15,J16,J31,J37,J38,
J39,J40,J42,J43,J47,
L611,R148,R149,
R153,R574,R803
J02,,J06,J10,J11,J17, JUMPER WIRE PITCH=10mm 531400010000
J18,J19,J22,J25,J26,
J29,J30,J32,J33,J48,
L101,L508,R613,
R624
J12,J20,J23,J24,J34, JUMPER WIRE PITCH=12.5mm 531400012500
J36,R506,R534
J04,J07,J08,J09,J14, JUMPER WIRE PITCH=20mm 531400020000
L504 JUMPER WIRE PITCH=20mm 531400020000
R620A TUBE HOT-SHRINK UL/CSA D=9X0.25mm L=30mm 531509003000
G2A,G2C CABLE TIE PLT1M L=100mm 7130K12 532000001000
ET17 NEW M/B RIVET ASSY ET17 571717303000D
U301P TRANSISTOR WASHER PIN GOOD 604S 712000300101
5S01 BRACKET BACK (ELO) 720114300103
5S05,5S06 BRACKET FOOT (ELO) 720114400301
5S07 BRACKET FBT (ET1) 720120500101
5S02 HEAT SINK SIDE (L) (ELO) ET17/19 730102500101
5S03 HEAT SINK SIDE (R) (ELO) 730102500401
Q516N HEAT SINK 60X24X30.5 18mm 730401900101
5S02M,5S03M SCREW CPM 3.0x8 Zn-Cc 771106050201
S101N SCREW CPTTB 4X8 Zn-Cc 771317050201
5S01N,5S07M, SCREW CPTSPB 3.0x8 Zn-Cc 771376050201
Q516,W202N
U301M SCREW CPTSPB 3.0x12 Zn-Cc 771376070201
5S07N SCREW CTTWC 4.0x10 Zn-Cc 773457060201
5S01M,Q501M, SCREW CTTWE 3.0x8 Zn 773656050201
Q508M,Q509M
Q602M SCREW CTTWE 3.0X14 Zn 773656080201
W202M SCREW R0313L41C IOHMF 4-40 Ni 775106050301
U301N NUT M3.0 3.0x0.5 Zn-Cc 780203010201
C506R,Q602R, RIVET d1.2Xd1.6Xd2.9X3.0L Cr 790800010501
R602R
L601AR RIVET d1.4Xd1.8Xd3.0X3.0L Cr 790800020501
L601R,L602R,Q509R RIVET d1.4Xd1.8Xd3.0X3.0L Cr 790800020501
D601R,D621R, RIVET d1.6Xd2.0Xd4.0X3.0L Cr 790800030501
D622R,L505R,
Q508R
C611R,S601R, RIVET d1.9Xd2.3Xd3.8X3.0L Cr 790800070501
T501R,T601R
