Elo TouchSystems ET1587C User Manual

- 79 -
PCB NECK CEM-I T1.6/1oz L82xW90mm FOR ET17 /19 441100310100
CRTA SOCKET CRT ISDW01S 01S44C INCHANGE 450010001700
G2 GT PIN R=1.56mm l=13mm 452001561300
T704 GT PIN R=2.36mm L=14mm 452002361400
T701 BASE PIN 2.5mm 7PIN R/A 452112500700
T703 BASE PIN 2.0mm 6PIN RA 453012000600
T702 BASE PIN 2.0mm 9PIN RA 453012000900
C728,K701,K702,K703, SPARK GAP 1.2KV 473500312200
K704
J702,J703,J710 JUMPER WIRE PITCH=7.5mm 531400007500
J701,J705,R719,R720, JUMPER WIRE PITCH=10mm 531400010000
R721
J706,J707,J708,J711 JUMPER WIRE PITCH=12.5mm 531400012500
J704 JUMPER WIRE PITCH=15mm 531400015000
J709 JUMPER WIRE PITCH=20mm 531400020000
ET17/19 CRT BOARD ASSY ET17/19 571909304000A
5S04 VIDEO SHIELDING GAME 720305200101
U703N HEAT SINK 60LX24WX30.5H 13mm 730401900301
U703M SCREW CTTWE 3.0x8 Zn 773656050201
