Elo TouchSystems ET1587C User Manual

- 94 -
T704 GT PIN R=2.36mm L=14mm 452002361400
T701 BASE PIN 2.5mm 7PIN R/A 452112500700
T703 BASE PIN 2.0mm 6PIN RA 453012000600
T702 BASE PIN 2.0mm 9PIN RA 453012000900
C728,K701,K702,K703, SPARK GAP 1.2KV 473500312200
K704
J702,J703,J710 JUMPER WIRE PITCH=7.5mm 531400007500
J701,J705,R719,R720, JUMPER WIRE PITCH=10mm 531400010000
R721
J706,J707,J708,J711 JUMPER WIRE PITCH=12.5mm 531400012500
J704 JUMPER WIRE PITCH=15mm 531400015000
J709 JUMPER WIRE PITCH=20mm 531400020000
ET17/19 CRT BOARD ASSY ET17/19 571909304000A
5S04 VIDEO SHIELDING GAME 720305200101
U703N HEAT SINK 60LX24WX30.5H 13mm 730401900301
U703M SCREW CTTWE 3.0x8 Zn 773656050201
571717303000E ((ET17F M/B RIVET ASSY))
CIRCUITREF DESCRIPTION PART NO.
R220,R502,R623 RES CF 1/8W 10ohm J T 211003010000
R134,R135,R136,R137, RES CF 1/8W 100ohm J T 211003010100
R146,R147,R223,R224,
R225
R104,R106,R110,R112, RES CF 1/8W 1K J(+/-5%) T 211003010200
R117,R131,R133,R138,
R207,R226,R511,R519,
R522,R523,R527,R562,
R565,R621,R635,R638
R142,R228,R310,R529, RES CF 1/8W 10K J(+/-5%) T 211003010300
R537,R631,R807
R202,R231 RES CF 1/8W 100K J T 211003010400
R229 RES CF 1/8W 10M J T 211003010600
R227 RES CF 1/8W 120K J T 211003012400
R309 RES CF 1/8W 13K J T 211003013300
R156,R308,R520,R526 RES CF 1/8W 1.5K J T 211003015200
R212 RES CF 1/8W 15K J T 211003015300
R625 RES CF 1/8W 150K J T 211003015400
R210 RES CF 1/8W 1.8K J T 211003018200
R501,R503,R619,R627 RES CF 1/8W 18K J T 211003018300
R515 RES CF 1/8W 200K J T 211003020400
R230 RES CF 1/8W 2M J T 211003020500
R103,R111,R113,R114, RES CF 1/8W 220ohm J(+/-5%) T 211003022100
R122,R123,R124,R125,
R126,R127,R128,R143,
R144,R200,R205,R206,
R208,R222,R554
