Elo TouchSystems ET1587C User Manual

- 96 -
R301,R301A,R302, RES CF 1/2W 3.9ohm J T 211203039800
R303,R304
R312 RES CF 1/2W 560ohm J T 211203056100
R636 RES CF 1/2W 680ohm J T 211203068100
R640 RES CF 1/2W 68K J T 211203068300
R639 RES CF 1/2W 680K J T 211203068400
R512 RES CF 1/2W 82K J T 211203082300
R505 RES HIGH 1/2W 18M T 211223018600
R571 RES MF 1/4W 1M F T 212103010500
R552 RES MOF 1W 47ohm J 12.5 212501047000
R536 RES MOF 2W 100K J(+/-5%) P:15mm 212601010400
R530 RES MOF 2W 0.18ohm J 15 212601018900
R615,R616 RES MOF 2W 68K J 15 212601068300
R617 RES MOF 3W 4.7K J 20 212701047200
R514 RES MOF 3W 56ohm J 20 212701056000
R525 RES MOF 3W 68ohm J 20 212701068000
R620 RES MOF normal sizee 5W 0.27ohm J KINK P=5 212852027900
L604 RES FUSIBLE(MF)
1/4W 0.33Ω J T
213653033900
R504,R535 RES FUSIBLE(MF)
1W 100Ω J P=12.5
213671010100
R572 RES FUSIBLE(MF)
2W 120Ω J P=15
213681012100
VR501 VR SEMI-FIXED B 20K M D=6 V 0.1W CF 221300020300
VR601 VR SEMI-FIXED B 1K M D=6 H 0.1W CF 221400010200
R600 PTCR 9ohm DGC2R9R0Q27A 2PIN 231000009000
R602 NTCR 3A 5ohm SCK053 231103050800
R614 VARISTOR 1A/150V PANJIT P6KE150A/5W DO-41 232500000000
SW5 ENCODER DC11B2021401 FORWARD FOR ET21 232600000700
C101,C104,C114 CAP ELEC 100uF M 10V 105 TAPING 261201310100
C622 CAP ELEC 220uF M 10V 105 TAPING 261201322100
C116 CAP ELEC 470uF M 10V 105 TAPING 261201347100
C217 CAP ELEC 10uF M 16V 105 T 261202310000
C612,C635 CAP ELEC 100uF M 16V 105 TAPING 261202310100
C301,C302,C626,C629 CAP ELEC 1000uF M 16V 105 +/-20%T 261202310200
C222 CAP ELEC 220uF M 16V 105 TAPING 261202322100
C106,C111,C212,C218 CAP ELEC 47uF M 16V 105 TAPING 261202347000
C628 CAP ELEC 2200uF M 25V 105 7.5 261203122200
C619 CAP ELEC 100uF M 25V 105 T 261203310100
C502 CAP ELEC 220uF M 25V 105 TAPING 261203322100
C620 CAP ELEC 47uF M 25V 105 T (20%) 261203347000
C307 CAP ELEC 220uF M 35V 105 TAPING 261204322100
C112,C113,C223,C537 CAP ELEC 10uF M 50V 105 T (20%) 261205310000
C513 CAP ELEC 1uF M 50V 105 TAPING 261205310800
C206,C216,C225,C547, CAP ELEC 2.2uF M 50V 105 TAPING 261205322800
C634
C105 CAP ELEC 3.3uF M 50V 105 TAPING 261205333800
C505 CAP ELEC 47uF M 50V 105 TAPING 261205347000
C633 CAP ELEC 100uF M 100V 105 T 261208310100
