4. Product-specific information EN
12.7.23 V2.1 11 / 24
4.2 Electrical data
4.2.1 Electrical parameters
Unit Value
4621273E
Value
4621213E
Min. switching voltage on DC safety output
V DC 10
Max. switching voltage on DC safety output
V DC 30
Max. switching voltage on DC control output
V DC 30
Min. switching voltage on AC safety output
V AC 10
Max. switching voltage on AC safety output
V AC 250
Max. switching voltage on AC control output
V AC 250
Min. switching current on safety output
A 0.01
Max. switching current on safety output
A 4
Max. switching current on control output
A 3
Min. switching capacity on safety output W
W 0.1
Max. switching capacity on safety output W
W 120
Max. switching capacity on control output W
W 90
Min. switching capacity on safety output VA
VA 0.1
Max. switching capacity on safety output VA
VA 1000
Max. switching capacity on control output VA
VA 750
Sensor system
NO / NC
Max. voltage on safety input in case of fault
N/A
60 V DC /
25 V AC
Max. switch on system reaction time
ms 100
Switch on reaction time when max. U
B
applied
ms 450
Switch on operating time
s 10
Max. switching frequency
Hz 0.1
Number of safety output relays
1
Number of control output relays
1
Number of redundant safety inputs
4
Stop category 0
EDM input
Usage category
AC-15: 230 V AC/1 A
DC-13: 24 V DC/1.2 A
Max. number of switching operations at 0.5 A switching
current (ohmic load) on control output
3.7 x 10
5
Max. number of switching operations at 3 A switching cur-
rent (ohmic load) on control output
1.8 x 10
5
Max. number of switching operations at 0.5 A switching
current (ohmic load) on safety output
3.7 x 10
5
