elobau 4621273E - Parameters for UL Approval

4. Product-specific information
12 / 24 www.elobau.com 9010041B01M
Tabelle 2
4.2.2 Parameters for UL approval
Tabelle 3
(1)
An external UL248 fuse with max. 1 A is required that is suitable for the
respective voltage.
“Only Cu” connection cables and temperature class 60/75
Max. number of switching operations at 4 A switching cur-
rent (ohmic load) on safety output
1.8 x 10
5
Overvoltage category
III
Pollution degree
2
Min. operating voltage DC
V DC 21.6
Max. operating voltage DC
V DC 26.4
Min. operating voltage AC
V AC 21.6 –
Max. operating voltage AC
V AC 26.4 –
Fuse for operating voltage,
fast-acting
1A
Safety output fuse, slow-acting
4 A
Control output fuse,
slow-acting
3 A
Max. current consumption
mA 200 295
Max. power consumption W
W 5.28 7.79
Max. power consumption VA
VA 5.28
Cross-circuit detection

LED display

4.2.1 Electrical parameters
Unit Value
4621273E
Value
4621213E
Cat. no. Input Output to Sen-
sor
Safety output Control output
4621273E 24 V AC/V DC,
200 mA
(1)
Max. 12 V DC Max. 4 A
max. 250 V AC /24 V DC
Pilot duty, 30 V DC 2 A
resistive
Max. 3 A
max. 250 V AC /
30 V DC
General purpose
4621213E 24 V DC,
295 mA
(1)
Max. 26.4 V DC
